Engineered for the Outback: Discover Our Australian-Patented Electric RV Roof Lifting Systems
For RV manufacturers catering to the rugged Australian landscape, reliability isn't just a feature—it's a necessity. We are proud to introduce our latest generation of Lifting Brackets for RV Roofs, officially registered with IP Australia (Design No. 202518071). Combining patented X-frame stability with high-performance linear actuators, our P-Series brackets are built to elevate your caravan's performance.
1. Certified Design, Proven Stability
Our system is more than just a bracket; it is a protected innovation designed by experts.
Patented Scissor Mechanism: The registered X-frame design ensures a perfectly level lift, even for heavy pop-top roofs in uneven terrain.
Ultra-Low Profile: When folded, our brackets maintain a compact height (as low as 92mm for model P05G1), minimizing wind resistance during travel.
Global Quality: Originally developed by Huzhou Andite Technology, this design meets the rigorous standards of the Australian Designs Act 2003.
2. High-Performance Specifications (The P-Series)
We offer three specialized models tailored to different RV load requirements:
| Feature | Model P04L | Model P04ML | Model P05G1 |
| Max Thrust (Actuator Load) |
9000N |
5000N |
3000N |
| Total Lift Weight & Life |
200kg (10,000 cycles) |
180kg (10,000 cycles) |
100kg (10,000 cycles) |
| Lifting Height Range |
105mm – 850mm |
105mm – 850mm |
92mm – 1050mm |
| Actuator Stroke |
140mm |
140mm |
160mm |
| Full Lift Time |
45 Seconds |
20 Seconds (Fast) |
93 Seconds |
| Unit Weight |
Lightweight 14.8kg |
Lightweight 14.8kg |
Compact/Light Load |
3. Why Choose Our Patented Lifting Solution?
Exceptional Durability: All models are tested for 10,000 cycles, ensuring years of trouble-free operation for your end users.
Versatile Applications: Whether you need the heavy-duty 9000N thrust of the P04L or the extended height of the P05G1 (up to 1050mm), we have the solution.
Market Exclusivity: Using our Australian Registered Design gives your brand a unique selling point that is legally protected in the Australian market.
Conclusion: Elevate Your Brand with Certified Excellence Don't compromise on the mechanism that literally supports your RV's reputation. Our P-Series lifting brackets provide the perfect balance of patented safety and industrial-grade power.
Ready to upgrade your production line?
Contact our technical sales team for the full P-Series data sheet or to request a sample for testing.
